Avanti S V2 80mm EDF Sport Jet - ARF PLUS from Freewing - FJ21235AP
Version Info: This is the V2 version which has many upgrades. See the features below for more details. It is also the ARF PLUS version for pilots who wish to install their own power system. All primary electronics including servos and landing gear come pre-installed, just add your own power system (EDF, motor, and ESC) to begin flying.
Renowned worldwide as the ultimate EDF sport jet blending precision performance in a sleek and affordable package, the Freewing 80mm Avanti S is a fan-favorite powerhouse. Building on the performance of the original Avanti S, the Avanti S V2 takes that performance to the next level!
Freewing has implementing various enhancements throughout the aircraft. Areas such as the landing gear, nose gear doors, control horns, and elevator hinges have been updated and strengthened to improve durability and performance. To top it off, the color scheme was updated to the one selected by our wonderful Motion RC customers!
Visit the Official Freewing Avanti S Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
New Color Scheme The Avanti S V2 sports a brand new, sleek, red and light gray color scheme that was picked by Motion RC customers in our Facebook group. |
 |
Powerful For your ARF PLUS we recommend the 12-blade EDF, a powerful 3658-2150Kv inrunner motor, and 100A thrust reversing ESC. |
 |
Improved Landing Gear Design The main gear shock absorber has been strengthened and optimized for better support, and the nose gear has been shortened, providing more stable ground handling, while also helping to minimize bounce on touch down. |
 |
Revised Cockpit The cockpit now includes a pilot and sports a clear canopy to provide an unobstructed view. |
 |
Redesigned Nose Gear Doors The nose gear door frame and gear doors have been redesigned to ensure tighter closure of the doors, minimizing drag and optimizing aerodynamic performance. |
 |
Grass-Friendly Shock absorbing, trailing link landing gear with large tires make grass field flying a breeze. |
 |
Precise With digital hybrid metal gear servos on all of the flying surfaces and brass ball link control hardware, the Avanti S V2 delivers precise responses to your control inputs. |
 |
Split Flaps The split flaps help execute short takeoffs and slow, controlled landing approaches. |
Features:
- New! Color scheme picked by Motion RC customers
- New! Optimized nose landing gear to reduce yaw and landing bounce
- New! Redesigned nose landing gear door frame and gear doors to optimize aerodynamics and keep doors closed tighter
- New! Thicker and stronger shock absorber parts in the main landing gear
- New! More hinges to the horizontal stabilizer for improved elevator hinge strength
- New! Upgraded control horns for more strength and reliability
- New! Revised cockpit with pilot added
- New! CG marker is now on the bottom of the wings
- New! No bare white foam to prevent aging and discoloration
- New! Fuselage belly protection strip prevents foam damage during landing, handling, and transport
- Officially licensed by SebArt International, the Avanti's original designer
- Digital hybrid metal gear servos throughout
- Optimized ducting that eliminates the need for a cheater hole
- Electric retracts and trailing link suspension struts for grass operation
- Removable wings with quick disconnect plug
- LED position lights on the wingtips, dorsal spine, and ventral keel
- Magnetic removable nose cone with plastic cap for durability
- Split flaps
Includes:
- Freewing Avanti S V2 80mm EDF Sport Jet - ARF PLUS
Requires:
- Brushless motor, EDF unit and ESC (see specifications for details)
- 6 Channel Radio - Select a minimum 6 channel radio from our Radio Collection
- 6 Channel Receiver - Select a minimum 6 channel receiver from our Receiver Collection
- 6 Cell 22.2V 4000 - 6000 mAh LiPo Battery with EC5 connector - we recommend Admiral 6 Cell 6000 mAh LiPo battery
- Minimum 6 Cell Battery Charger - Select a minimum 6 Cell battery charger from our Battery Collection
Product Specifications:
Wingspan |
1236mm / 48.7in |
Length |
1300mm / 51.2in |
Flying Weight |
~2800g / 98.7oz |
CG (Center of Gravity) |
105-110mm where wing's LE meets fuselage (see manual diagram) |
Power System |
3658-2150Kv brushless inrunner motor (recommended) |
Electronic Speed Control |
100A thrust reversing ESC with EC5 connector (recommended) |
Propeller / EDF |
80mm EDF with 12-blade fan (recommended) |
Servos |
|
Landing Gear |
Electric retracts and trailing link suspension struts for grass operation |
Required Battery |
6S 22.2V 4000-6000mAh LiPo with EC5 connector |
Required Radio |
6+ channel |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Split |
Lights |
Yes |
Hinge Type |
Nylon reinforced hinges |
Material |
EPO foam |
Skill Level |
Advanced |
Build Time |
1 Hour |
Recommended Environment |
Outdoor |
Videos
Product Videos
Spare Parts
Product Spare Parts
1 - 32 of 52 results
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
If you need any additional assistance, please visit the Motion RC Help Center
Customer Reviews
- Reviews
Freewing Avanti S V2 80mm EDF ARF
Excellent product. Drop in installation of spare 80mm EDF and ESC unit from earlier Freewing product. Great flyer stock. Even more exciting with Freewing thrust vector unit install modification.
Freewing Avanti V2
This plane appears to be very good quality. I also had the V1 Avanti and the upgrades are very well thought out and implemented. I hope to maiden it very...read more
Avanti V2 is a Winner
I've had several of the V1's and the V2 has some subtle refinements but remains one of the best EDFs out there.
best in its class
flys fantastic, love it
Avanti vs FMS Futura/Integral
The Avanti wins first place. The Avanti has a larger battery compartment so you can use various battery sizes. The FMS Jets do not allow for various battery sizes,Unless you...read more
Good stuff
Best sport jet ever
-
