LAZER ZX7 1/10 Scale 2WD Buggy - KIT from Kyosho - KYO30048B
Version Info: This buggy is a KIT, and will require electronics, paint, tires and other equipment (see Requires below for details).
Having maintained its brilliant record in major races throughout Japan and around the world with minor improvements since its launch, the LAZER ZX-6 has fully evolved into the new ZX-7. Over this time the racing landscape has changed significantly with many circuits using high-grip carpet and artificial turf. In addition, the power and speed of electric off road cars has increased dramatically. While maintaining the signature mild control and dynamic maneuverability of the ZX-6, the new narrow main chassis design of the ZX-7 provides optimal rigidity and lighter weight while the new front suspension and aero body with rear wing design generates more downforce. These performance improvements go together with the essential elements of reliability and durability as well as a wider range of settings that will give the ZX-7 the leading edge in modern racing and it is backed by Motion RC's world-renowned customer service and technical support. Drive on!
Visit the Official Kyosho LAZER ZX7 1/10 Scale 2WD Buggy Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Improved Steering and Supension New short front gullwing arms and wider arm mounts deliver improved steering and suspension feel. New adjustable hub carrier can be set to 7°, 10°, and 13° caster angles. |
|
Chassis Flex New resin floating servo mount and improved front and rear chassis braces maintains optimal chassis flex. |
 |
 |
Improved Feel and Reliability New improved lightweight slipper clutch replaces the center gear diff for improved throttle feel. New joint cup covers reduce wear and improves reliability. |
|
High Grip Performance New rear upper bulkhead with lower roll centers improves high grip performance. Adjustable length rear arms carried over from the RB7 offer even more tuning options. |
 |
Features:
- 2mm shorter front gullwing arms and wider front aluminum arm mounts
- Caster adjustable front hub carriers 7°, 10°, 13° with revised ackerman knuckles
- Lower roll center rear upper bulkhead
- Wide rear aluminum arm mount
- .5mm thinner 7075 hard anodized aluminum chassis for improved flex
- Front and rear chassis braces also improving flex characteristics
- Floating servo mount
- Lightweight slipper clutch with front and rear gear diffs
- Wing and screw on mounts from the RB7
- Adjustable length rear arms from the RB7
- 1.6mm and 1.7mm 2 hole pistons and shock caps from the RB7
- 74mm universal swingshafts for the front end
Includes:
- Kyosho LAZER ZX7 1/10 Scale 2WD Buggy - KIT
- Unassembled kit
- Clear body & wing
- Wheels
- X-GEAR ball diff grease, high graphite grease, shock springs
Requires:
- 2-channel R/C system (1x servo and 1x ESC)
- 540 Size Motor (20T-27T recommended)
- 7.2V 1800mAh NiMH battery
- Tires and Inserts
- Pinion Gear
- Paint (body comes out of the box unpainted)
- NiMH compatible battery charger - we recommend the SkyRC B6AC V2 50W 6 Cell (6S) AC/DC LiPo Battery Charger
Product Specifications:
Model Scale |
1/10 |
Length |
385mm / 15.1in |
Width |
248mm / 9.7in |
Height |
145mm / 5.7in |
Weight (No Battery) |
1650g / 58.2oz |
Wheelbase |
278mm / 10.9in |
Ground Clearance |
N/A |
Body |
ABS Plastic |
Chassis |
N/A |
Drivetrain |
N/A |
Wheel Size (Diameter x Width) |
N/A |
Wheel Hex Size |
N/A |
Tire Tread |
Front: 210mm / Rear: 200mm |
Bushing Material |
N/A |
Suspension |
N/A |
Shock Type |
Oil-Filled |
Transmission |
N/A |
Gear Pitch |
N/A |
Internal Gear Ratio |
2:6:1 |
Final Drive Ratio |
N/A |
Pinion |
N/A |
Spur Gear |
N/A |
Differential |
N/A |
Ball Bearings |
N/A |
Brakes |
N/A |
Electronic Speed Control |
45A |
Motor |
5 turn 540 type (G15 motor) |
Battery |
7.2V 1800mAh NiMH battery (required) |
Max Battery Dimensions (L x W x H) |
N/A |
Servos |
N/A |
Radio |
Syncro KT-231P+ transmitter |
Lights |
No |
Sound |
No |
Water Resistant |
N/A |
Skill Level |
Intermediate |
Assembly Time |
1 Hour |
Recommended Environment |
Offroad |
