Zeus 90mm 8S EDF Sport Jet from Freewing - PNP - FJ32021P
Version Note: This is the 8S version which comes with a 90mm 12-Blade EDF 8S Power System with a 4075-1350Kv inrunner brushless motor and a thrust reversing 120A ESC.
The 90mm Zeus is the latest sport jet offering from Freewing. Featuring a sporty and highly aerodynamic design, the Zeus 90mm is Freewing’s fastest sport jet yet, with this 8S version reaching speeds of 150 miles per hour (240 kmh) in level flight. Additionally, the blue, grey and white livery offers an attractive, bold presence that can be seen easily in the skies. Impressively designed, the wings are glue and screw-free utilizing a quick release wing lock mechanism that makes installing and removing the wings a simple and quick experience.
Each control surface is managed by a 17 gram metal gear servo for quality and confidence. Offered in 6S, 8S and ARF PLUS, the Zeus promises to deliver the most powerful thrust-to-weight ratio of all the Freewing sport jets before it. Take to the skies and experience the incredible thrill and neck-turning speed of the Zeus!
Visit the Official Freewing Zeus 90mm EDF Sport Jet Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Feel The Need For Speed? The Freewing Zeus 90mm EDF is the fastest sport jet developed by Freewing to date. At 150mph straight-line speed out of the box (8S PNP), the Zeus is sure to quench your thirst for acceleration. |
 |
Quick-Install & Release Wings The Zeus 90mm EDF features a screwless quick release wing design that makes field assembly and disassembly a breeze. |
 |
Slow Your Roll The Zeus includes a thrust-reversing ESC (PNP versions) enabling a brake-like effect, effectively reducing your roll out on landings. This is especially useful on shorter, paved runways. |
 |
Grass Friendly The Zeus 90mm EDF sport jet comes with CNC-machined struts with a trailing link design that can handle most reasonably-mowed grass fields with ease. |
 |
Navigation and Position Lights The Zeus features daylight-bright LED lights on the wing tips, top and bottom of the fuselage, as well as a landing light that is mounted on the nose gear strut. |
 |
Vivid Color Scheme The color scheme on the Zeus is bright and vivid, providing great visibility in all types of situations and conditions. |
 |
Great Sound and Power The Zeus 90mm EDF 8S PNP sports the new 12-blade 90mm EDF unit with a powerful 4075-1350Kv inrunner motor for high end EDF jet performance. |
 |
Full Landing Gear Doors The Zeus has fully sequenced gear doors, including inner main gear doors for lower drag and better sport jet performance. |
Features:
- Our fastest 8S sport jet yet, capable of speeds of 150mph (240kmh) in level flight
- Sleek, aerodynamic design for incredible sport jet performance
- Quick release main wings provide a simple and easy process for installing and removing the wings
- CNC-machined landing gear struts with trailing link design for better grass-field operations
- Daylight-bright LED lights located on the wing tips, top and bottom of the fuselage and a landing light on the nose gear strut
- 12-blade, factory-balanced EDF combined with a 3668-1960Kv (6S) or 4075-1350Kv (8S) brushless inrunner motor for top end EDF jet performance and great sound
- 120 Amp ESC with 8A UBEC with thrust reversing
- (7) 17g, digital, metal gear metal gear servos for all control surfaces
- (2) 9g, digital, hybrid metal gear servos for nose gear steering and nose gear doors
- Fully sequenced gear doors, including inner main gear doors for lower drag and better performance
- Nylon hinges on all control surfaces
Includes:
- Freewing Zeus 90mm 8S EDF Sport Jet - PNP
- 12-Blade EDF power system (installed)
- 4075-1350Kv brushless inrunner motor (installed)
- 120A ESC with reverse thrusting and EC5 connector (installed)
- Electronic retractable landing gear (installed)
- Servos, LED Lights (installed)
Requires:
- 7 Channel radio - select a minimum 7 channel radio from our Radio Collection
- 7 Channel receiver - select a minimum 7 channel receiver from our Receiver Collection
- TWO 4 Cell 14.8V 6000 mAh LiPo batteries with EC5 connector - EPR60004E
- OR -
ONE 6 Cell 22.2V 5000 mAh LiPo battery with EC5 connector AND ONE 2 Cell 7.4V 5000 mAh LiPo with EC5 connector - EPR50006 AND EPR50002E - EC5 2-to-1 series adapter - BenchCraft EC5 2 to 1 Series Adapter with 10 Gauge Silicone Wire
- 6 Cell compatible battery charger - select a minimum 6 cell (6S) charger from our Charger Collection
Product Specifications:
Model Scale |
N/A |
Wingspan |
1200mm / 47.24in |
Length |
1450mm /57.08in |
Empty Weight |
2820g / 99.47oz (w/o battery) |
CG (Center of Gravity) |
120mm (4.7") from the leading edge of the wing at the root |
Power System |
8S 4075-1350Kv Brushless Inrunner Motor |
Electronic Speed Control |
120A thrust reversing, EC5 Connector |
Propeller / EDF |
90mm 12-Blade EDF |
Servos |
|
Landing Gear |
Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts |
Required Battery |
6 Cell 22.2V 5000 mAh LiPo and 2 Cell 7.4V 5000 mAh LiPo batteries with EC5 connector in series |
Required Radio |
7 Channel (required) |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Lights |
Yes |
Hinge Type |
Nylon Reinforced |
Material |
EPO Foam |
Skill Level |
Intermediate |
Build Time |
1 Hour |
Recommended Environment |
Outdoor, 150+ foot paved runway or short manicured grass |
