P-40 Warhawk 1570mm (61.8") Wingspan - ARF from Nexa - NXA1009-001
The Curtiss P-40 Warhawk is an American single-engined, single-seat, all-metal fighter and ground-attack aircraft that first flew in 1938. The P-40 design was a modification of the previous Curtiss P-36 Hawk which reduced development time and enabled a rapid entry into production and operational service. The Warhawk was used by most Allied powers during World War II, and remained in frontline service until the end of the war. It was the third most-produced American fighter of World War II, after the P-51 and P-47; by November 1944, when production of the P-40 ceased, 13,738 had been built, all at Curtiss-Wright Corporation's main production facilities at Buffalo, New York.
The Nexa P-40 Warhawk is a .60 size electric or gas option scale series warbird with a 1570mm wingspan, constructed primarily from balsa wood and covered with a fuel-resistant covering. This ARF requires assembly and installation of your choice of servos and power system, and includes split flaps, painted pilot, machine gun and other scale details. The large battery hatch affords ample room for either electric or gas setups. Impress at your flying field with this iconic stunner!
Visit the Official Nexa P-40 Warhawk 1570mm ARF Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Fully Covered and Detailed The Nexa P-40 Warhawk comes fully covered including simulated panel lines, rivets, nomenclature and weathering detail. |
 |
Scale Details Throughout There is no shortage of scale details with this P-40 including functional split flaps, machine guns, and painted pilot. |
 |
Prehinged and Installed Control Surfaces All control surfaces come out of the box fully prehinged and installed for your convenience. |
 |
Large Battery Hatch The P-40 has a large battery hatch area to fit an array of LiPo battery sizes. |
Features:
- Complete Balsa and lite-ply construction for rigidity and durability
- Covered from tip to tail in scale details including weathering, functional split flaps, printed simulated panel lines and rivets
- Fiberglass cowling for strength and durability
- The hand-painted pilot is ready for your added cockpit details
- Some control surfaces come out of the box pre-hinged and installed for convenience
- Large battery hatch allows for your chosen electric or gas setup
Includes:
- Nexa P-40 Warhawk 1570mm (61.8") Wingspan - ARF
- Fixed, thick wire landing gear. Note: the retracts and struts shown in the photos are not included, but are available in the spare parts tab
- Fuel tank, hardware and servo trays
Requires:
- 6 Channel radio - select a minimum 6 channel radio from our Radio Collection
- 6 Channel receiver - select a minimum 6 channel receiver from our Receiver Collection
- Brushless outrunner motor - we recommend the Admiral GP10 5030-400Kv Brushless Motor
- 60-75 Amp brushless ESC - we recommend the ZTW Mantis G2 65A ESC with 8A SBEC
- 6x standard servos for ailerons, flaps, elevator and rudder - we recommend the Hitec HS-485HB Deluxe Ball Bearing Karbonite Gear Standard Servo Airplane Multi-Pack (6 Servos)
- Electric retracts - we recommend Nexa Rotating Electronic Main Retract (Set of 2)
- 6 Cell 22.2V 5000 mAh LiPo Battery - we recommend the Admiral 5000mAh 6S 22.2V 50C LiPo Battery with EC5 Connector
- 14x9 or 15x7 3-Blade Electric propeller - we recommend the Master Airscrew 14x9 3-Blade Electric Propeller
- 6 Cell compatible battery charger - select a minimum 6 cell (6S) charger from our Charger Collection
Gas Requires:
- 2 stroke engine - we recommend the NGH GT17 17cc Two-Stroke Engine
- 2 blade gas propeller - we recommend the APC 15x8 Gas Propeller
Nexa ARF models are constructed out of balsa wood and plywood. These are not foam models. The assembly of balsa wood ARF aircraft requires basic model building skills including the installation of servos, ESC, and motor (or gas engine).
Product Specifications:
Model Scale |
1/7 |
Wingspan |
|
Length |
1360mm / 53.5in |
Weight |
N/A |
CG (Center of Gravity) |
100-105mm from the leading edge of the wing's root |
Power System |
400Kv Brushless outrunner motor for electric or 2-stroke for gas (required) |
Electronic Speed Control |
60-75A (required) |
Propeller / EDF |
14x9 3-blade for electric or 15x8 gas 2-blade for gas (required) |
Servos |
|
Landing Gear |
Electric retractable (required) |
Required Battery |
6 Cell 22.2V 5000 mAh LiPo Battery (required) |
Required Radio |
6+ Channel (required) |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Lights |
No |
Hinge Type |
Nylon |
Material |
Balsa and light plywood |
Skill Level |
Intermediate |
Build Time |
6+ Hours |
Recommended Environment |
Outdoors |
Videos
Product Videos
Spare Parts
Product Spare Parts
1 - 24 of 24 results
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
If you need any additional assistance, please visit the Motion RC Help Center
Customer Reviews
- Reviews
P40 Warhawk
I've been looking at the Next P40 warhawk for a while, I bought a 20cc gas engine for it. Its a rear exhaust engine, I bought from another hobby supplier....read more
very good quality, not the easiest assembly
I received the plane in great shape although fedex took longer than I thought they should, but that's not motion's fault. Everything was well packed, and I suggest watching the...read more
P40
Always wanted a P40. Now I can afford one. Quality kit. Great price.
Nexa P-40 Warhawk
Beautiful model. Parts fit together well. Only one big complain: weak retract landing gears. Nice and smooth landing, one retract gear folded on my first landing. The weak aileron servo...read more
P40
Servo mounts were not very good.
-
