F-5 Tiger II Swiss High Performance 80mm EDF Jet - PNP from Freewing - FJ20825P
Version Info: This is the High Performance version which, as of 2/26/2024, includes a powerful 3658-2150Kv inrunner brushless motor with a new 12-blade fan.
Introducing the fifth jet in Freewing's 80mm EDF Jet Series, the iconic F-5 Tiger II. This comes in the Swiss livery. Freewing’s rendition incorporates a thicker airfoil to enhance the lifting body design of the original F-5, imparting the stability of an RC model with the standoff scale looks of the real jet. This High Performance version now includes a new 9-blade fan and powerful 3658-1920Kv brushless inrunner motor, offering speed and scale agility in a stable platform that also looks great in a never before modeled color scheme. Bring something unique to your RC airfield!
Freewing's 80mm F-5 Tiger II is the perfect size for easy transport without the need for disassembly. For more versatile transportation or compact storage options, the rigid, carbon fiber reinforced wings are removable with screws, as are the unique vertical stabilizers, and full flying horizontal stabilizers. Hybrid gear servos on the full flying horizontal stabilizers ensure positive control, and pre-installed flaps help to slow down landings. Designed for operation on pavement or very short grass, the F-5 features aluminum trailing link struts all around for durability, and the shock absorbing struts dampen hard landings to reduce bouncing. Plastic main gear doors and a spring-hinged full coverage nose gear door minimize drag and maximize speed.
For pilots who have flown other aircraft in Freewing's 80mm Jet Series, the F-5 Tiger II is stable like the F-86 Sabre, and is slightly slower than the Mirage 2000 with a less axial roll rate, making the F-5 an ideal first 80mm jet. The three tone desert camouflage color scheme is very easy to see against a blue sky, and the included missiles aid in visibility. The F-5 is optimized to fly our Admiral 6s 4000mAh lipo battery with an EC5 connector, but it can also accommodate the Admiral 4500mAh or 5000mAh. Pre-installed electronics and control hardware minimizes assembly time to about one hour. The Freewing 80mm F-5 Tiger II is recommended for Intermediate to Advanced pilots only.
Features:
- New! 80mm 12-blade ducted fan and powerful 3658-2150Kv brushless inrunner motor provides awesome power and incredible real life jet turbine sound
- Model officially licensed by Northrop Grumman
- Super scale details include hand painted, scale-sized pilot and full instrument panel
- Eye-catching Swiss livery
- 100 Amp ESC with 5A BEC
- Electronic retractable landing gear with all metal shock-absorbing struts
- Steerable, shock absorbing nose gear for enhanced ground maneuverability
- Spring operated nose gear door
- Carbon spars and EPO foam construction provide the perfect balance between strength and flexibility
- Nylon hinges on all control surfaces (superior to foam hinges)
- Gapless flap hinges
- Inrunner motor, servos, ESC and EDF come pre-installed for your convenience
- Removable wings and stabilizers for convenient transport
Includes:
- Freewing F-5 Tiger II Swiss High Performance 80mm EDF Jet - PNP
Requires:
- 6 Channel Radio - Select a minimum 6 channel radio from our Radio Collection
- 6 Channel Receiver - Select a minimum 6 channel receiver from our Receiver Collection
- 6 Cell 22.2V 4000 mAh LiPo Battery with EC5 connector - EPR40006PRO
- 6 Cell Compatible Battery Charger - Select a minimum 6 cell (6S) charger from our Charger Collection
Product Specifications:
Wingspan |
800mm / 31.49in |
Length |
1250mm / 49.21in |
Flying Weight |
2200g / 78oz |
CG (Center of Gravity) |
Please refer to the manual |
Power System |
3658-2150Kv Brushless Inrunner Motor |
Electronic Speed Control |
100A ESC, 5A BEC, EC5 Connector |
Propeller / EDF |
80mm Metal EDF with 12-Blade Fan |
Servos |
|
Landing Gear |
Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts |
Required Battery |
6S 22.2V 4000mAh-5000mAh LiPo (required) |
Required Radio |
6 Channel |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Lights |
No |
Hinge Type |
Nylon hinges |
Material |
EPO Foam |
Skill Level |
Advanced |
Build Time |
30 Minutes |
Recommended Environment |
Outdoor |
Videos
Product Videos
Spare Parts
Product Spare Parts
0 - 32 of 59 results
Upgrades
Product Upgrades
1 - 12 of 12 results
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
Product Updates:
- June 27, 2015 - The Swiss version of this model does NOT include a weapons set.
